ABB 1SDA100425R1 XT5S 630 Ekip Dip LS/I In=630 3p F F 630A 3-Pole Fixed Molded Case Circuit Breaker

The ABB 1SDA100425R1 XT5S 630 Ekip Dip LS/I In=630 3p F F is a high-performance molded case circuit breaker (MCCB) from the ABB Tmax XT5 series, delivering a rated current of 630A across 3 poles with an exceptional breaking capacity of 85 kA at 220 V AC. Designed for demanding industrial power distribution applications, the XT5S 630 Ekip Dip LS/I In=630 3p F F combines advanced Ekip Dip LS/I trip technology with a compact fixed-mount form factor — providing reliable overload protection and short circuit protection in a package weighing just 4.82 kg.

Technical Specifications

Certifications & Standards

• RoHS: Compliant with EU Restriction of Hazardous Substances requirements
• REACH: Compliant with EU REACH chemical safety regulation
• EU Directive 2011/65/EU: Restriction of hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Updated RoHS substance restriction list compliance
• IEC 60947-2: Low-voltage switchgear and controlgear — circuit breakers standard
• IEC61850: Communication standard for intelligent electronic devices in electrical substations
• CE: Conformité Européenne marking — meets EU health, safety, and environmental protection requirements

Applications & Use Cases

The XT5S 630 Ekip Dip LS/I In=630 3p F F MCCB is engineered for a wide range of industrial and commercial power distribution scenarios where robust overload protection and short circuit protection are critical. Typical applications include main distribution boards, motor feeders, transformer protection, and industrial panel boards in manufacturing facilities, data centres, utilities, and infrastructure projects. The Ekip Dip LS/I adjustable trip unit allows engineers to fine-tune long-time (L), short-time (S), and instantaneous (I) protection settings directly on the device, ensuring precise coordination with upstream and downstream protective devices. The fixed frame size and compact footprint make the XT5S an excellent choice for space-constrained switchgear assemblies requiring IEC 60947-2-compliant power circuit breaker performance.
