ABB 1SDA100355R1 XT5N 630 Ekip Dip LS/I In=630 3p F F 630A 3-Pole Fixed Moulded Case Circuit Breaker

The ABB 1SDA100355R1 — catalog number XT5N 630 Ekip Dip LS/I In=630 3p F F — is a 630A, 3-pole fixed-mount power circuit-breaker from the Tmax XT5 series, engineered for reliable protection of transformers, generators, and installation systems. With a breaking capacity of 70 kA at 220 V AC and integrated Ekip Dip LS/I trip unit, this breaker delivers precise overload and short-circuit protection in demanding industrial environments. Compact at 140 mm × 205 mm × 103.5 mm and weighing just 4.82 kg, it fits seamlessly into space-constrained control panels.

Technical Specifications

Certifications & Standards

• RoHS: Compliant with EU Restriction of Hazardous Substances Directive
• REACH: Compliant with EU REACH regulation on chemical safety
• EU Directive 2011/65/EU: Restriction of hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Updated substance restrictions under EU Directive 2011/65/EU
• IEC 60947-2: Meets international standard for low-voltage circuit-breakers
• IEC 61850: Supports the international standard for communication networks in substations
• WEEE: Compliant with EU Waste Electrical and Electronic Equipment Directive

Applications & Use Cases

• Transformer and generator feeder protection in industrial power distribution
• Main and sub-main circuit protection in commercial and industrial switchboards
• Installation protection in manufacturing plants, data centres, and utility infrastructure
• Integration into intelligent low-voltage switchgear with IEC 61850 communication
• Control panel and motor control centre (MCC) installations requiring high breaking capacity

Frequently Asked Questions

What does the catalog number XT5N 630 Ekip Dip LS/I In=630 3p F F indicate?

XT5N identifies the breaker frame and voltage rating; 630 is the frame size; Ekip Dip LS/I denotes the digital trip unit with long-time (L), short-time (S) and instantaneous (I) protection functions; In=630 sets the rated current; 3p means 3-pole; F F denotes fixed execution for both incoming and outgoing terminals.

What is the breaking capacity of the ABB 1SDA100355R1?

The ABB 1SDA100355R1 (XT5N 630 Ekip Dip LS/I In=630 3p F F) offers a breaking capacity of 70 kA at 220 V AC, making it suitable for high short-circuit current environments.

Is this circuit-breaker compatible with IEC 61850?

Yes. The XT5N 630 Ekip Dip LS/I In=630 3p F F supports IEC 61850, enabling integration with digital substation and intelligent switchgear communication systems.

What is the EAN barcode for this product?

The EAN barcode is 8056221004329, corresponding to ABB SKU 1SDA100355R1.
