ABB 1SDA104952R1 YU-C XT5 W 380...440 Vac Undervoltage Release Circuit Breaker Accessory

% $-93.27
ABB 1SDA104952R1 YU-C XT5 undervoltage release accessory - withdrawable
ABB 1SDA104952R1 YU-C XT5 undervoltage release accessory - withdrawable

ABB 1SDA104952R1 YU-C XT5 W 380...440 Vac Undervoltage Release Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA104952R1
Catalog No: YU-C XT5 W 380...440 Vac
Series: Accessories for Tmax XT
Tariff Code (HS): 853890
Breaking Type: Undervoltage Release (YU)
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$93.27

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA104952R1 (YU-C XT5 W) is a wired undervoltage release for withdrawable Tmax XT5 molded case circuit breakers, built to trip the breaker automatically on loss or collapse of supply voltage so the load cannot restart unexpectedly. It takes an AC coil rated 380...440 V and weighs 0.116 kg.

Technical Specifications

SKU 1SDA104952R1
Brand ABB
Series Accessories for Tmax XT
Extended Product Type YU-C XT5 W 380...440 Vac
EAN 8015644070441
Function Undervoltage Release, wired
Compatible Breaker Mounting Withdrawable (W), Tmax XT5
Rated Voltage (Ur) 380...440 V AC
Current Type AC
Configuration Type Loose or configurable
Net Weight 0.116 kg

Certifications & Standards

  • IEC 60947-2
  • UL 489

Selection Notes

This undervoltage release uses a single AC coil rating (380...440 V), narrower than the dual AC/DC 220...240/220...250 V variant in the same XT5 withdrawable family - pick whichever matches the actual control voltage available at the panel. Like all YU releases, it opens the breaker on loss of voltage rather than on command, protecting against an unexpected automatic restart when supply returns.

Technical Details

Short Description
ABB 1SDA104952R1 - YU-C undervoltage release, wired, for withdrawable Tmax XT5 MCCB, 380-440V AC coil, 0.116 kg.
Catalog No
YU-C XT5 W 380...440 Vac
Standards
IEC60947-2, UL489
Delivery Date (Days)
30 days
Model Number
YU-C XT5 W 380...440 Vac
Tariff Code
853890
