ABB 1SDA104951R1 YU-C XT5 W 220..240 Vac - 220..250 Vdc Undervoltage Release Circuit Breaker Accessory

% $-93.27
ABB 1SDA104951R1 YU-C XT5 undervoltage release accessory - withdrawable
ABB 1SDA104951R1 YU-C XT5 undervoltage release accessory - withdrawable

ABB 1SDA104951R1 YU-C XT5 W 220..240 Vac - 220..250 Vdc Undervoltage Release Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA104951R1
Catalog No: YU-C XT5 W 220..240 Vac - 220..250 Vdc
Series: Accessories for Tmax XT
Tariff Code (HS): 853890
Breaking Type: Undervoltage Release (YU)
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$93.27

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

Fitted to withdrawable Tmax XT5 molded case circuit breakers, the ABB 1SDA104951R1 (YU-C XT5 W) is a wired undervoltage release that trips the breaker automatically if the supply voltage collapses, so the load does not restart unexpectedly when voltage returns. Its coil accepts 220...240 V AC or 220...250 V DC, and the part weighs 0.12 kg.

Technical Specifications

SKU 1SDA104951R1
Brand ABB
Series Accessories for Tmax XT
Extended Product Type YU-C XT5 W 220..240 Vac - 220..250 Vdc
EAN 8015644070434
Function Undervoltage Release, wired
Compatible Breaker Mounting Withdrawable (W), Tmax XT5
Rated Voltage (Ur) 220...240 V AC | 220...250 V DC
Current Type AC/DC
Configuration Type Loose or configurable
Net Weight 0.12 kg

Certifications & Standards

  • IEC 60947-2
  • UL 489

Selection Notes

YU identifies an undervoltage release, which trips the breaker when the monitored supply drops below its pickup threshold - the opposite function to a shunt trip (YO) accessory. This variant's dual AC/DC coil (220...240 V AC or 220...250 V DC) suits control circuits fed from either a transformer or a battery/DC bus. It fits the withdrawable (W) XT5 frame only; the fixed/plug-in frame needs the F/P part instead.

Technical Details

Short Description
ABB 1SDA104951R1 - YU-C undervoltage release, wired, for withdrawable Tmax XT5 MCCB, 220-240V AC or 220-250V DC coil, 0.12 kg.
Catalog No
YU-C XT5 W 220..240 Vac - 220..250 Vdc
Standards
IEC60947-2, UL489
Delivery Date (Days)
30 days
Model Number
YU-C XT5 W 220..240 Vac - 220..250 Vdc
Tariff Code
853890
