ABB 1SDA104693R1 XT5 W FP 630A 4p EF EF IEC/UL Withdrawable Circuit Breaker Accessory

% $-415.96
ABB 1SDA104693R1 XT5 Withdrawable Fixed Part - 630A 4P IEC/UL
ABB 1SDA104693R1 XT5 Withdrawable Fixed Part - 630A 4P IEC/UL

ABB 1SDA104693R1 XT5 W FP 630A 4p EF EF IEC/UL Withdrawable Circuit Breaker Accessory

Brand: ABB
Reference No: 1SDA104693R1
Catalog No: XT5 W FP 630A 4p EF EF IEC/UL
Series: Accessories for Tmax XT
Tariff Code (HS): 853890
Rated Voltage: 600 V AC / 600 V DC
Poles: 4P
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$415.96

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The ABB 1SDA104693R1 is a withdrawable, IEC/UL dual-listed fixed part for the Tmax XT5 moulded case circuit breaker, rated 630 A (IEC) / 600 A (UL) over four poles with extended front (EF) terminals. It carries the disconnecting contacts the draw-out breaker racks into and is sized for installations needing both IEC 60947-2 and UL 489 compliance.

Technical Specifications

SKU 1SDA104693R1
Brand ABB
Series Tmax XT
Catalog Designation XT5 W FP 630A 4p EF EF IEC/UL
EAN 8015644067854
Sub-type XT5
Configuration Type Loose or configurable
Number of Poles 4P
Rated Current (In) 600 A
Rated Uninterrupted Current (Iu) 630 A (IEC) / 600 A (UL)
Rated Operational Voltage (Ue) 600 V AC / 600 V DC
Rated Frequency 50/60 Hz
Terminal Connection Type Withdrawable Circuit-Breakers, Front Extended
Net Weight 21.7 kg

Certifications & Standards

  • IEC/EN 60947-2
  • UL 489

Selection Notes

This is the only withdrawable, dual IEC/UL fixed part at the 630 A frame size in the group, so pick it over the IEC-only 400 A withdrawable parts whenever the project both needs draw-out isolation and must satisfy UL 489. As with the plug-in version of this rating, size downstream cable and protection to the 600 A UL figure rather than the 630 A IEC figure on projects carrying UL listing.

Technical Details

Short Description
ABB Tmax XT5 withdrawable fixed part, 630 A, 4-pole, extended front terminals, IEC/UL, for XT5 MCCB.
Rated Voltage (VAC)
600 V AC / 600 V DC
Mounting Type
Withdrawable
Catalog No
XT5 W FP 630A 4p EF EF IEC/UL
Number of Poles
4P
Standards
IEC60947-2, UL489
Delivery Date (Days)
30 days
Model Number
XT5 W FP 630A 4p EF EF IEC/UL
Tariff Code
853890
