Harting 19200031440 Han A hood 3A - single lever top entry M20

Harting 19200031440 Han A Single-Lever Hood 3A Top Entry M20 Heavy Duty Connector Hood

Name: Harting 19200031440 Han A Single-Lever Hood 3A Top Entry M20 Heavy Duty Connector Hood
Brand: Harting
SKU: 19200031440
Price: 4.82 USD
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Brand: Harting

Reference No: 19200031440

Catalog No: 19 20 003 1440

Series: Han A

Tariff Code (HS): 853890

Stock: 0

Delivery time: 30 business day(s)

Shipping Origin: Türkiye EXW

$4.82

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

Description

The Harting 19200031440 is a Han A hood in size 3 A, with a single locking lever and one top-entry M20 cable gland. The zinc die-cast shell is powder-coated RAL 7037 and rated IP44 as supplied, reaching IP65/IP67 once the separate seal screw is fitted, for service from -40 to +125 °C.

Technical Specifications

Article number	19200031440
Article number (formatted)	19 20 003 1440
Brand	Harting
Series	Han A
GTIN	5713140124585
Category	Hoods / Housings
Type	Hood
Locking type	Single locking lever
Size	3 A
Version	Top entry
Number of cable entries	1
Cable entry	1x M20
Note	Seal screw ordered separately
Degree of protection (IEC 60529)	IP44 \| IP65 with seal screw \| IP67 with seal screw
UL 50 / UL 50E type rating	12
Limiting temperature	-40 ... +125 °C
Material (housing)	Zinc die-cast
Surface finish	Powder-coated
Colour	RAL 7037 (dust grey)
Net weight	61.4 g
Country of origin	Germany
European customs tariff number	85389099

Certifications & Standards

UL 1977
CE
UKCA
DNV GL
EN 45545-2

Selection Notes

As supplied this hood is only IP44 - order the seal screw separately if the installation needs the IP65/IP67 rating, since it is not bundled with the hood. Top entry suits panels where the cable has to drop straight down into the gland rather than approach from the side, which is the main layout difference against the Han B hoods in this size range. Zinc die-cast construction is specific to the Han A series; it is lighter than the aluminium die-cast used on Han B but has the same -40 to +125 °C rating.

Technical Details

Short Description

Han A hood, size 3 A, single lever, top entry, 1x M20, IP44 (IP65/IP67 with seal screw).

Mounting Type

Top entry

Protection Type

IP44 (IP65/IP67 with seal screw)

Catalog No

19 20 003 1440

Delivery Date (Days)

30 days

Model Number

Single-Lever Hood

Tariff Code

853890
