ABB 1SVR730020R0200 CT-MVS.21S Multifunction Timer Relay 2C/O 24-240V AC/DC 4A 250V CT-S Series
Brand:
ABB
Reference No:
1SVR730020R0200
Catalog No:
CT-MVS.21S
Series:
CT-S
Tariff Code (GTIP):
85364900
Stock: 49
Delivery time: 1 business day(s)
Shipping Origin: Turkey EXW
$93.70
- Description
The ABB CT-MVS.21S (SKU: 1SVR730020R0200) is a multifunction timer relay from the CT-S series, offering 2 changeover contacts and a wide supply voltage range of 24–240V AC/DC, making it ideal for flexible industrial automation and control panel applications. The CT-MVS.21S supports multiple timing functions in a single compact 22.5mm DIN rail device, reducing inventory complexity and simplifying panel design. Rated at 4A / 250V, it is engineered to meet the demands of machine builders, system integrators, and panel builders worldwide.
Technical Specifications
| Catalog Number | CT-MVS.21S |
| SKU | 1SVR730020R0200 |
| Brand | ABB |
| Series | CT-S |
| Product Type | Timer Relay (Multifunction) |
| Contacts | 2 C/O (2 Changeover) |
| Supply Voltage | 24–240V AC/DC |
| Rated Current | 4 A |
| Rated Voltage | 250 V |
| Dimensions (W × H × D) | 22.5 mm × 85.6 mm × 103.7 mm |
| Weight | 0.148 kg |
| EAN | 4016779851381 |
Certifications & Standards
- CAN/CSA C22.2 No.14: Canadian Standards Association approval for industrial control equipment
- IEC/EN 63000: Technical documentation for the assessment of electrical and electronic products with respect to the restriction of hazardous substances
- IEC/EN 61812-1: Specified performance requirements for time relays for industrial and residential use
- UL 508: UL standard for industrial control equipment
- IEC 60715: Dimensions of low-voltage switchgear and controlgear — standardized mounting on rails
- EN 61812: European standard for time relays used in industrial and residential applications
- CSA C22.2: Canadian electrical safety standard for industrial control equipment
- CSA: Canadian Standards Association product certification
- REACH: EU regulation on registration, evaluation, authorisation and restriction of chemicals
- RoHS: Restriction of hazardous substances in electrical and electronic equipment
- CCC: China Compulsory Certification for market access in China
- cULus: Combined UL certification valid for both the US and Canada
- CE: European conformity marking — meets all applicable EU directives
- UKCA: UK Conformity Assessed marking for the Great Britain market
Technical Details
Catalog No
CT-MVS.21S
Delivery Date (Days)
1 days
Model Number
CT-MVS.21S
Tariff Code
85364900
