ABB 1SDA101115R1 XT7S 1000 Ekip Dip LS/I In=1000A 4p F F 4-Pole 1000A Fixed Moulded Case Circuit Breaker for Transformer Generator Installation Protection

The ABB 1SDA101115R1 XT7S 1000 Ekip Dip LS/I In=1000A 4p F F is a heavy-duty 4-pole fixed-mount power circuit breaker rated at 1000 A, delivering a breaking capacity of 85 kA at 220 V AC. Part of ABB's Tmax XT7S series, the XT7S 1000 Ekip Dip LS/I In=1000A 4p F F is engineered for reliable protection of transformers, generators, and electrical installations in demanding industrial environments. With its Ekip Dip LS/I trip unit, this breaker provides precise long-time and instantaneous protection for critical power distribution systems.

Technical Specifications

Certifications & Standards

• CE: Compliant with applicable EU directives for electrical equipment
• RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances
• REACH: Compliant with EU REACH regulation on chemical safety
• EU Directive 2011/65/EU: Restriction of hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Updated RoHS substance restrictions per EU amendment
• IEC 60947-2: Compliant with international standard for low-voltage switchgear — circuit breakers
• UL 2799: Listed per UL standard for electrical systems
• WEEE: Compliant with EU Waste Electrical and Electronic Equipment Directive for responsible disposal

Applications & Use Cases

• Transformer protection in medium and large industrial facilities
• Generator protection in power generation and backup power systems
• Main and feeder circuit protection in industrial control panels
• Installation protection in commercial and heavy industrial applications
• Power distribution boards requiring high breaking capacity up to 85 kA
