ABB 1SDA100847R1 XT7S 1000 Ekip Touch Meas.LSI 1000 3p FF 1000A 3-Pole Fixed Power Circuit Breaker

The ABB 1SDA100847R1 — catalog number XT7S 1000 Ekip Touch Meas.LSI 1000 3p FF — is a 1000 A, 3-pole fixed-mounted power circuit breaker from the Tmax XT7S series, designed for transformer, generator, and installation protection in demanding industrial applications. Featuring the Ekip Touch Meas.LSI trip unit with measurement capabilities and LSI (Long-time, Short-time, Instantaneous) protection functions, this breaker delivers precise overcurrent protection alongside real-time electrical measurement in a compact fixed (FF) format.

Technical Specifications

Certifications & Standards

• IEC 60947-2: Compliant with the international standard for low-voltage circuit breakers
• CE: Meets European conformity requirements for electrical equipment
• RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances
• REACH: Compliant with EU REACH regulation on chemical substances
• EU Directive 2011/65/EU: RoHS 2 directive compliance
• Amendment 2015/863: Compliant with the updated RoHS substance restrictions
• UL 2799: UL certification for applicable standards
• WEEE: Registered under the Waste Electrical and Electronic Equipment directive

Applications & Use Cases

The XT7S 1000 Ekip Touch Meas.LSI 1000 3p FF is engineered for critical power distribution and protection duties including:

• Transformer primary and secondary protection in industrial switchboards
• Generator circuit protection in power generation installations
• Main and sub-main distribution boards in commercial and industrial facilities
• Installation protection in motor control centres (MCC) and distribution panels
• Applications requiring integrated measurement and LSI overcurrent protection in a single device
