ABB 1SDA100720R1 XT6N 1000 Ekip Dip LS/I In=1000 3p F F 1000A 3-Pole Fixed Moulded Case Circuit Breaker

The ABB XT6N 1000 Ekip Dip LS/I In=1000 3p F F (SKU: 1SDA100720R1) is a 1000A, 3-pole fixed-mounted power circuit-breaker from the Tmax XT6 series, engineered for transformer, generator, and installation protection in demanding industrial environments. Featuring the Ekip Dip LS/I trip unit with long-time and instantaneous protection functions, it delivers a breaking capacity of 70 kA at 220 V AC, ensuring robust fault clearing capability for critical power distribution systems.

Technical Specifications

Certifications & Standards

• IEC 60947-2: Compliant with the international standard for low-voltage switchgear and controlgear — circuit-breakers
• CE: Meets European conformity requirements for electrical equipment placed on the EU market
• RoHS: Compliant with the Restriction of Hazardous Substances Directive — restricted substances within permitted limits
• REACH: Compliant with EU REACH regulation on chemical safety and substances of very high concern
• EU Directive 2011/65/EU: Verified compliance with the EU RoHS Directive on hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Compliant with the 2015 amendment to Directive 2011/65/EU extending the restricted substances list
• WEEE: Registered under the Waste Electrical and Electronic Equipment Directive for responsible end-of-life disposal

Applications & Use Cases

The XT6N 1000 Ekip Dip LS/I In=1000 3p F F power circuit-breaker is purpose-built for protection of transformers, generators, busbars, and main distribution boards in industrial plants, commercial buildings, data centres, and infrastructure projects. Its Ekip Dip LS/I trip unit allows straightforward DIP-switch setting of protection thresholds on-site without additional software, making commissioning fast and reliable. The fixed (F F) execution suits main incoming panel positions where withdrawable mechanisms are not required, optimising panel depth and installation cost. With a 70 kA breaking capacity at 220 V AC, the XT6N 1000 handles high prospective fault currents found downstream of large power transformers and generator sets, providing upstream discrimination and minimising system downtime during fault events.
