ABB 1SDA068480R1 XT4S 250 Ekip M Dip I In=250A 3p F F Moulded Case Circuit Breaker 250A 3P Fixed 85kA

The ABB 1SDA068480R1 XT4S 250 Ekip M Dip I In=250A 3p F F is a 250A, 3-pole fixed-mounted moulded case circuit breaker from the Tmax XT4 series, engineered for reliable trafo, generator, and installation protection. Delivering a breaking capacity of 85 kA at 220 V AC, the XT4S 250 Ekip M Dip I In=250A 3p F F is designed to meet the demanding requirements of industrial power distribution panels and control systems. Compact in footprint yet robust in performance, this ABB circuit breaker is a trusted choice for engineers specifying high-fault-level protection in critical electrical infrastructure.

Technical Specifications

Certifications & Standards

• RoHS: Compliant with Restriction of Hazardous Substances requirements
• REACH: Compliant with EU REACH chemical safety regulation
• EU Directive 2011/65/EU: Restriction of hazardous substances in electrical and electronic equipment
• Amendment 2015/863: Updated RoHS substance restriction list compliance
• IEC 60947-2: International standard for low-voltage circuit-breakers
• UL 2799: UL safety certification for applicable markets
• ATEX: Certified for use in potentially explosive atmospheres
• CE: Conforms to applicable European Union directives
• VDE: Tested and certified by the German VDE Institute
• WEEE: Compliant with the Waste Electrical and Electronic Equipment directive

Applications & Use Cases

• Transformer and generator protection in industrial power distribution systems
• Main and sub-main circuit protection in commercial and industrial installations
• Control panel and switchboard integration requiring high breaking capacity
• Motor feeder protection where high fault levels are present
• Offshore, hazardous area, and ATEX-classified installations
