ABB 1SDA067861R1 XT2H 160 Ekip Dip LS/I In=160A 3p F F 160A 3-Pole Fixed Moulded Case Circuit Breaker

The ABB 1SDA067861R1 XT2H 160 Ekip Dip LS/I In=160A 3p F F is a 160 A, 3-pole fixed moulded case circuit-breaker from the Tmax XT2 series, purpose-engineered for transformer, generator, and installation protection in industrial control panels. Featuring the Ekip Dip LS/I electronic trip unit with long-time and instantaneous protection functions, the XT2H 160 Ekip Dip LS/I In=160A 3p F F delivers precise, configurable overcurrent protection in a compact 90 × 130 × 82.5 mm footprint weighing just 1.4 kg.

Technical Specifications

Certifications & Standards

• IEC 60947-2: Compliant with the international standard for low-voltage switchgear — circuit-breakers
• CE: Conforms to applicable European Union directives for the European Economic Area
• ATEX: Approved for use in potentially explosive atmospheres per EU ATEX directive
• VDE: Tested and certified by VDE, Germany's leading electrotechnical testing institute
• UL 2799: Listed under UL standard 2799 for additional North American market compliance
• RoHS: Compliant with EU Directive 2011/65/EU on restriction of hazardous substances in electrical equipment
• Amendment 2015/863: Compliant with the RoHS amendment expanding restricted substances under EU Directive 2015/863
• REACH: Compliant with EU REACH regulation (EC No 1907/2006) on chemical substance safety
• WEEE: Registered under the Waste Electrical and Electronic Equipment Directive for responsible end-of-life disposal
• EU Directive 2011/65/EU: Full RoHS directive compliance confirmed for all restricted hazardous substances

Applications & Use Cases

• Transformer primary and secondary circuit protection in industrial and commercial installations
• Generator output protection for standby and prime power applications
• Feeder and outgoing circuit protection in main distribution boards and motor control centres
• Installation protection in industrial automation control panels and switchgear assemblies
• Use in hazardous area installations where ATEX-rated components are required
