ABB 1SDA070761R1 E1.2N 800 Ekip Dip LI 3p F F 800A 3P 66kA Fixed Power Circuit Breaker

The ABB 1SDA070761R1 E1.2N 800 Ekip Dip LI 3p F F is a 800A, 3-pole fixed-mount power circuit breaker from the SACE Emax2 E1.2 series, delivering a breaking capacity of 66 kA at 400 V AC. Engineered for demanding transformer, generator, and installation protection applications, the E1.2N 800 Ekip Dip LI 3p F F features ABB's advanced Ekip Dip LI trip unit combining Long-time (L) and Instantaneous (I) protection functions in a compact, robust package weighing just 14 kg.

Technical Specifications

Certifications & Standards

• CE: Conforms to EU Machinery and Low Voltage Directive requirements for the European market
• IEC: Designed and tested in accordance with IEC standards for low-voltage switchgear
• RoHS: Compliant with EU Directive 2011/65/EU (Restriction of Hazardous Substances)
• REACH: Compliant with EU REACH regulation on chemical safety
• EU Directive 2011/65/EU: RoHS Directive compliance confirmed
• Amendment 2015/863: Updated RoHS restricted substances compliance
• UL 2799: UL certification applicable to this product family
• ATEX: Suitable for use in explosive atmosphere classified environments per ATEX directive
• CSA: Canadian Standards Association certified for North American markets
• VDE: German VDE mark confirming compliance with DIN/VDE electrical standards
• WEEE: Registered under the Waste Electrical and Electronic Equipment Directive for responsible disposal

Applications & Use Cases

• Main incomer and feeder protection in low-voltage switchboards and distribution panels
• Transformer secondary protection — withstands high inrush currents without nuisance tripping
• Generator circuit protection in standby and prime power installations
• Industrial installation protection in manufacturing plants, data centres, and infrastructure facilities
• Bus-tie and bus-section switching in medium to large MV/LV substations
