Siemens 6ES7923-0BA50-0FB0 TOP Connect IDC Cable PLC Connection Module - 8 I/O 0.5m

Siemens 6ES7923-0BA50-0FB0 SIMATIC TOP Connect Cable IDC to Open End 8 I/O 0.5m

Name: Siemens 6ES7923-0BA50-0FB0 SIMATIC TOP Connect Cable IDC to Open End 8 I/O 0.5m
Brand: Siemens
SKU: 6ES7923-0BA50-0FB0
Price: 46.51 USD
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Brand: Siemens

Reference No: 6ES7923-0BA50-0FB0

Catalog No: 6ES7923-0BA50-0FB0

Series: SIMATIC TOP connect

Tariff Code (HS): 85444290

Rated Voltage: 24 V

Stock: 0

Delivery time: 10-15 business day(s)

Shipping Origin: Türkiye EXW

$46.51

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

Description

The Siemens 6ES7923-0BA50-0FB0 is a 16-pin round cable that connects an 8 I/O TOP connect connection module to the control system. One end carries an IDC connector for the connection module; the other end has labeled open wires with end sleeves for direct termination on the control side. Unshielded, 0.14 mm2 conductors, 0.5 m long.

Technical Specifications

SKU	6ES7923-0BA50-0FB0
Brand	Siemens
Series	SIMATIC TOP connect
Product Designation	Pre-Assembled Round Cable
EAN	4047623603573
Target System	Control
Suitability	Digital I/O modules
Operating Voltage (DC), Rated	24 V
Operating Voltage (DC), Maximum	60 V
Number of Channels	8
Wire Length	0.5 m
Conductor Cross Section	0.14 mm2
Number of Poles	16
Interface 1 (Control Side)	10-pin, open ends with end sleeve
Interface 2 (Connection Module Side)	16-pin, IDC connector
Connector Type	IDC connector
Electrical Connection, Enclosure	End sleeve
Electrical Connection, Field	Connector strip
Cable Design	Round cable
Cable Sheath Material	PVC
Cable Sheath Color	Black
Cable Outer Diameter	6.5 mm
Ambient Temperature, Operation	0 ... 60 degC
Ambient Temperature, Storage	-30 ... +70 degC
Net Weight	0.058 kg
Country of Origin	Germany

Selection Notes

The open, labeled ends with end sleeves on the 6ES7923-0BA50-0FB0 let it land directly on a control-system terminal block without a second TOP connect module in between, which is the difference from the CB0 cable that runs IDC-to-IDC between two modules. At 0.5 m it suits a connection module mounted close to the control terminals; pick the 1.0 m version when that distance is greater.

Technical Details

Short Description

TOP connect cable, IDC to open end with sleeves, 8 I/O, 0.14mm2, unshielded, 0.5m.

Rated Voltage (VAC)

24 V

Catalog No

6ES7923-0BA50-0FB0

Delivery Date (Days)

10-15 days

Model Number

6ES7923-0BA50-0FB0

Tariff Code

85444290
