Siemens 6AU1435-2AD00-0AA2 SIMOTION D435-2 DP/PN STANDARD Motion Controller

The Siemens 6AU1435-2AD00-0AA2 is a SIMOTION D435-2 DP/PN drive-based motion controller with standard performance, built for multi-axis machine control. It provides 12 digital inputs, 16 configurable digital I/Os, 6 DRIVE-CLiQ ports, 2 PROFIBUS interfaces, 3 PROFINET ports, 2 Ethernet ports, 2 USB ports, and 1 option slot, and ships with a double fan module included. Net weight is 3.7 kg.

Technical Specifications

Selection Notes

The DP/PN designation reflects the built-in PROFIBUS DP and PROFINET interfaces on this control unit, letting it act as fieldbus master on both networks from the base unit. This -0AA2 variant ships with a double fan module rather than the fan/battery combination used on related D435-2 hardware, so plan a separate real-time-clock battery if long-term retentive backup is required. With 12 DI, 16 configurable DI/DO, and 6 DRIVE-CLiQ ports, it suits machines that combine PROFINET IO devices with isochronous drive axes on one controller.
