Siemens 5SV6016-7KK20 Residual Current Device

Siemens 5SV6016-7KK20 5SV6 20A 2P 230V Residual Current Device

Name: Siemens 5SV6016-7KK20 5SV6 20A 2P 230V Residual Current Device
Brand: Siemens
SKU: 5SV6016-7KK20
Price: 339.96 USD
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Brand: Siemens

Reference No: 5SV6016-7KK20

Catalog No: 5SV6016-7KK20

Series: 5SV6

Rated Current: 20A

Rated Voltage: 230V

Poles: 2

Stock: 0

Delivery time: 1-2 business day(s)

Shipping Origin: Türkiye EXW

$339.96

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

Description

The Siemens 5SV6016-7KK20 is a afdd/mcb from the SENTRON/SIRIUS 5SV6 series. AFDD-MCB-Combination 230V, 6kA, 1+N, C, 20A Compact (1MW). Supplied by Stoklink for industrial and commercial low-voltage applications.

Technical Specifications

SKU	5SV6016-7KK20
Brand	Siemens
Series	5SV6
Product Type	Residual Current Device
Product brand name	SENTRON
Product designation	AFDD/MCB
Design of the product	Compact unit
Number of poles	2
Design of pole	1P+N
Tripping characteristic class	C
Size of installation devices according to DIN 43880	1
Mechanical service life (operating cycles) typical	10 000
Switching function short-term delayed	No
Overvoltage category	3
Degree of pollution	2
Type of voltage of the operating voltage	AC
At AC	230 V
Value range of the supply voltage frequency	50Hz
Protection class IP	IP20, with connected protective device and conductors
According to EN 60898-1 rated value	6 000 A
According to IEC 60947-2 rated value	6 000 A
Energy limitation class	3
Weight	0.12 kg
Country of Origin	CN

Applications & Use Cases

The Siemens 5SV6016-7KK20 is used in industrial control panels, distribution boards and automation systems. As part of the Siemens 5SV6 range it integrates with compatible SENTRON/SIRIUS components for a coordinated low-voltage installation. Genuine Siemens product supplied by Stoklink with fast dispatch from Türkiye.

Technical Details

Rated Current (Ampere)

20A

Rated Voltage (VAC)

230V

Catalog No

5SV6016-7KK20

Number of Poles

Delivery Date (Days)

1-2 days

Model Number

5SV6
