Siemens 5SV6016-7KK06 5SV6 6A 2P 230V Residual Current Device

% $-298.13
Siemens 5SV6016-7KK06 Residual Current Device
Siemens 5SV6016-7KK06 Residual Current Device

Siemens 5SV6016-7KK06 5SV6 6A 2P 230V Residual Current Device

Brand: Siemens
Reference No: 5SV6016-7KK06
Catalog No: 5SV6016-7KK06
Series: 5SV6
Rated Current: 6A
Rated Voltage: 230V
Poles: 2
Stock: 0
Delivery time: 1-2 business day(s)
Shipping Origin: Türkiye EXW
$298.13

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Siemens 5SV6016-7KK06 is a afdd/mcb from the SENTRON/SIRIUS 5SV6 series. AFDD-MCB-Combination 230V, 6kA, 1+N, C, 6A Compact (1MW). Supplied by Stoklink for industrial and commercial low-voltage applications.

Technical Specifications

SKU 5SV6016-7KK06
Brand Siemens
Series 5SV6
Product Type Residual Current Device
Product brand name SENTRON
Product designation AFDD/MCB
Design of the product Compact unit
Number of poles 2
Design of pole 1P+N
Tripping characteristic class C
Size of installation devices according to DIN 43880 1
Mechanical service life (operating cycles) typical 10 000
Switching function short-term delayed No
Overvoltage category 3
Degree of pollution 2
Type of voltage of the operating voltage AC
At AC 230 V
Value range of the supply voltage frequency 50Hz
Protection class IP IP20, with connected protective device and conductors
According to EN 60898-1 rated value 6 000 A
According to IEC 60947-2 rated value 6 000 A
Energy limitation class 3
Weight 0.133 kg
Country of Origin DE

Applications & Use Cases

The Siemens 5SV6016-7KK06 is used in industrial control panels, distribution boards and automation systems. As part of the Siemens 5SV6 range it integrates with compatible SENTRON/SIRIUS components for a coordinated low-voltage installation. Genuine Siemens product supplied by Stoklink with fast dispatch from Türkiye.

Technical Details

Rated Current (Ampere)
6A
Rated Voltage (VAC)
230V
Catalog No
5SV6016-7KK06
Number of Poles
2
Delivery Date (Days)
1-2 days
Model Number
5SV6
