Siemens 5SL6506-6YA 5SL6 1P+N 6A 6kA 230V B-Curve Miniature Circuit Breaker

The Siemens 5SL6506-6YA is a two-pole miniature circuit breaker (MCB) from the SENTRON 5SL6 series, rated 6 A with a B tripping characteristic and 6 kA breaking capacity (IEC 60947-2 / EN 60898-1) at 400 V AC. Designed for overload and short-circuit protection of cables and equipment in final distribution circuits, it mounts on a standard 35 mm DIN rail and occupies 2 modular width unit(s).

Technical Specifications

Certifications & Standards

• IEC 60947-2
• EN 60898-1

Applications & Use Cases

The 5SL6506-6YA provides B-characteristic protection suited for resistive and lightly inductive loads such as lighting, sockets and general distribution. At 6 A and 6 kA breaking capacity, it is dimensioned for final subcircuit protection in commercial, residential and light-industrial distribution boards conforming to IEC 60947-2.

DIN-rail mounting and 2-module width allow high-density installation in standard consumer units and panelboards. Halogen-free construction and sealable toggle support fire-safety and lock-out requirements in institutional and infrastructure applications.
