Siemens 4RB2150-3EE50 4RB2 440V Power Supply

Name: Siemens 4RB2150-3EE50 4RB2 440V Power Supply
Brand: Siemens
SKU: 4RB2150-3EE50
Price: 96.68 USD
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Brand: Siemens

Reference No: 4RB2150-3EE50

Catalog No: 4RB2150-3EE50

Series: 4RB2

Rated Voltage: 440V

Stock: 0

Delivery time: 1-2 business day(s)

Shipping Origin: Türkiye EXW

$96.68

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

Description

The Siemens 4RB2150-3EE50 is a power supply from the SENTRON/SIRIUS 4RB2 series. Power capacitor PHICAP MKP 440 V 15.0 kVAr. Supplied by Stoklink for industrial and commercial low-voltage applications.

Technical Specifications

SKU	4RB2150-3EE50
Brand	Siemens
Series	4RB2
Product Type	Power Supply
Type of internal interconnection	D (Delta)
Type of certification	CE
Type of enclosure material	Extruded round aliuminum can with stud
Type of mechanical safety	Overpressure disconnector (3-phase)
Standard	IEC 60831-1 / -2
Capacitor voltage (rms value) rated value	440 V
Operating frequency 1 rated value	50 Hz
Operating frequency 2 rated value	60 Hz
Capacity rated value	82 µF
Relative negative tolerance of the capacity rated value	5 %
Relative positive tolerance of the capacity rated value	1 %
Reactive power of the capacitor at 50 Hz rated value	15 kvar
Reactive power of the capacitor at 60 Hz rated value	18 kvar
Clearance minimum	9.6 mm
Creepage distance minimum	12.7 mm
Type of dielectric	Self-healing metallized polypropylene film
Filler	filled with Non PCB, Soft biodegradable resin
Safety features of the integrated discharge resistors	Discharge time ≤ 180 s to 75 V or less for safe discharging
Weight	1.99 kg
Country of Origin	IN

Certifications & Standards

IEC 60831-1

Applications & Use Cases

The Siemens 4RB2150-3EE50 is used in industrial control panels, distribution boards and automation systems. As part of the Siemens 4RB2 range it integrates with compatible SENTRON/SIRIUS components for a coordinated low-voltage installation. Genuine Siemens product supplied by Stoklink with fast dispatch from Türkiye.
