Schneider Electric LC1D32F7 TeSys Deca 3-Pole 32A 480V AC Coil 20HP Power Contactor

The Schneider Electric LC1D32F7 is a TeSys Deca series 3-pole power contactor rated at 32A with a 480V AC coil, designed for motor control and power switching applications up to 20HP. Engineered to IEC standards with a 100kA SCCR rating, the LC1D32F7 delivers reliable performance in demanding industrial environments where dependable motor starting and switching is essential.

Technical Specifications

Applications & Use Cases

• Motor Starting & Control: Suitable for direct-on-line starting of 3-phase motors up to 20HP in AC-3 utilization category applications.
• Industrial Automation: Widely used in conveyor systems, pumps, fans, compressors, and HVAC equipment requiring reliable power switching.
• Motor Control Centers (MCCs): Compatible with TeSys Deca accessories including auxiliary contact blocks and overload relays for complete motor starter assemblies.
• OEM Panel Building: Compact design and high SCCR rating (100kA) make the LC1D32F7 ideal for UL-listed control panels in commercial and industrial machinery.

Frequently Asked Questions

What is the coil voltage of the LC1D32F7?

The LC1D32F7 is fitted with a 480V AC coil, making it directly compatible with standard North American 480V control circuits without the need for a step-down transformer.

Can the LC1D32F7 be used with a thermal overload relay?

Yes. The TeSys Deca LC1D32F7 contactor is designed to accept clip-on TeSys Deca overload relays (LRD series) to form a complete IEC motor starter combination.

What auxiliary contacts are compatible with the LC1D32F7?

TeSys Deca LA1D series auxiliary contact blocks can be mounted to the front or side of the LC1D32F7 to add additional NO/NC signalling contacts as required by the control scheme.

What is the SCCR rating of the LC1D32F7?

The LC1D32F7 carries a Short-Circuit Current Rating (SCCR) of 100kA, meeting the requirements for UL 508A industrial control panel listings.
