Schneider Electric ZBRT2 Harmony XB5R Wireless Transmitter Module Black Double Action Control Unit

The Schneider Electric ZBRT2 is a Harmony XB5R transmitter module for wireless and batteryless push buttons, fitting beneath a Harmony XB5 head rather than supplying its own cap. It is a double action transmitter: It provides 1 radio frame sent at the push of the button and 1 radio frame sent at its release.

Technical Specifications

Certifications & Standards

• IEC 60947-1
• IEC 60947-5-1
• UL 508
• CSA C22.2 No 14
• GOST
• C-tick
• CCC
• BT 2006/95/EC

Selection Notes

This is the transmitter module only, for building a custom-colour or custom-marking wireless push button from a separate Harmony XB5 head, rather than buying a complete pre-assembled ZB5RTA unit. The double-action frame on both press and release suits applications that need to know both when the button is pressed and when it is let go, such as dead-man or hold-to-run logic. It is only compatible with receiver ZBRRp v2.0+, relay antenna ZBRA1 v2.0+ and access point ZBRNp v1.2+ or later.
