Schneider Electric ZBRT1 Harmony XB5R Wireless Transmitter Module Plastic Black Single Action Control Unit

% $-75.35
Schneider Electric ZBRT1 Harmony XB5R wireless transmitter module single action
Schneider Electric ZBRT1 Harmony XB5R wireless transmitter module single action

Schneider Electric ZBRT1 Harmony XB5R Wireless Transmitter Module Plastic Black Single Action Control Unit

Brand: Schneider Electric
Reference No: ZBRT1
Catalog No: ZBRT1
Series: Harmony XB5
Tariff Code (HS): 853690
Communication: Zigbee Green Power 2.4 GHz (IEEE 802.15.4)
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$75.35

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric ZBRT1 is a Harmony XB5R transmitter module for wireless and batteryless push buttons, fitting beneath a Harmony XB5 head rather than supplying its own cap. It is a single action transmitter: It provides 1 radio frame sent at the push of the button.

Technical Specifications

Reference ZBRT1
Brand Schneider Electric
Range of Product Harmony XB5
GTIN 3606480334726
Product or Component Type Wireless and batteryless transmitter
Device short name XB5R
Bezel material Plastic
Mounting diameter 22 mm
Communication port protocol Zigbee Green Power 2.4 GHz (IEEE 802.15.4)
Transmission frequency 2405 MHz
Number of channels 16
Maximum sensing distance 100 m free field; up to 300 m with relay antenna ZBRA1
Response time < 2 ms
Overall dimensions (W x H x D) 30 x 41.5 x 43 mm
Net weight 0.025 kg
IP degree of protection IP30 (back face)
Ambient air temperature, operation -40...70 °C
Fixing mode Nut beneath head, 2...2.4 N.m

Certifications & Standards

  • IEC 60947-1
  • IEC 60947-5-1
  • UL 508
  • CSA C22.2 No 14
  • GOST
  • C-tick
  • CCC
  • BT 2006/95/EC

Selection Notes

This is the transmitter module only, for building a custom-colour or custom-marking wireless push button from a separate Harmony XB5 head, rather than buying a complete pre-assembled ZB5RTA unit. Use this single-action version for a standard momentary push function. It is only compatible with receiver ZBRRp v2.0+, relay antenna ZBRA1 v2.0+ and access point ZBRNp v1.2+ or later.

Technical Details

Short Description
Harmony XB5R wireless batteryless transmitter module, single action, black, 22 mm.
Mounting Type
22 mm panel mount
Protection Type
IP30 (back face)
Catalog No
ZBRT1
Delivery Date (Days)
30 days
Model Number
XB5R
Tariff Code
853690
