Schneider Electric ZBRRC Harmony XB5R Programmable Receiver 4 PNP 200 mA 24 V DC Control Unit

% $-100.03
Schneider Electric ZBRRC Harmony XB5R programmable receiver 4 PNP DIN rail
Schneider Electric ZBRRC Harmony XB5R programmable receiver 4 PNP DIN rail

Schneider Electric ZBRRC Harmony XB5R Programmable Receiver 4 PNP 200 mA 24 V DC Control Unit

Brand: Schneider Electric
Reference No: ZBRRC
Catalog No: ZBRRC
Series: Harmony XB5R
Tariff Code (HS): 853690
Rated Current: 0.2 A
Communication: Zigbee Green Power 2.4 GHz (IEEE 802.15.4)
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$100.03

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric ZBRRC is a Harmony XB5R programmable receiver with 4 PNP transistor outputs (200 mA each), DIN-rail mounted and supplied at 24 V DC. It is built to interface wireless ZB5RTA/ZBRT pushbuttons directly to a PLC's digital inputs rather than to relay-switched field circuits.

Technical Specifications

Reference ZBRRC
Brand Schneider Electric
Range of Product Harmony XB5R
GTIN 3606480334719
Product or Component Type Programmable receiver
Device short name ZBRRC
Function of module Monostable
Output type Transistor PNP
Output contacts 4 PNP
Maximum switching current 0.2 A DC
Minimum switching current 10 mA DC
[Us] rated supply voltage 24 V DC +/- 15 %
Maximum power consumption 20 W DC
Maximum sensing distance 100 m free field; 15 m with transmitter in plastic box, receiver in metal enclosure
Response time < 30 ms after transmitter press
Mounting support 35 mm symmetrical DIN rail
Overall dimensions (W x H x D) 36 x 108 x 75 mm
Net weight 0.13 kg
IP degree of protection IP20

Certifications & Standards

  • CE
  • UL
  • UKCA
  • FCC
  • IC
  • CCC
  • Giteki
  • IEC 61010-1
  • IEC 60947-1
  • ETSI EN 300 328
  • IEEE 802.15.4

Selection Notes

Choose this receiver over the relay-output ZBRRA when the wireless pushbutton signal needs to go straight into a PLC or other 24 V DC PNP input card — 4 independent outputs let a single receiver serve up to 4 separate wireless buttons or functions. It is fixed to monostable logic, so where bistable or stop/start behaviour is needed the relay-output ZBRRA is the better fit.

Technical Details

Short Description
Harmony XB5R programmable receiver, 4 PNP outputs, 200 mA, 24 V DC, DIN rail.
Rated Current (Ampere)
0.2 A
Mounting Type
35 mm DIN rail
Protection Type
IP20
Catalog No
ZBRRC
Delivery Date (Days)
30 days
Model Number
ZBRRC
Tariff Code
853690
