Schneider Electric ZB4BZ101 Harmony XB4 Contact Block Body Mounting Collar 1NO Screw Clamp Control Unit

The Schneider Electric ZB4BZ101 is a Harmony XB4B complete body/contact assembly with a built-in metal fixing collar and a single 1 NO contact on screw-clamp terminals. It carries a 10 A conventional free-air thermal current and mounts behind a compatible XB4B operator head to form a complete pushbutton or selector switch station.

Technical Specifications

Certifications & Standards

• BV
• UL
• CSA
• DNV
• LROS
• CSA C22.2 No 14
• IEC 60947-5-1
• UL 508
• JIS C8201-5-1
• IEC 60947-5-4
• IEC 60947-5-5
• IEC 60947-1
• JIS C8201-1

Selection Notes

Without positive opening, this NO contact is a general control-logic block rather than a certified safety-interlock contact, so pick the 1 NC sibling with IEC 60947-5-1 Appendix K positive opening whenever the application needs a guaranteed-open contact for a safety circuit. The built-in metal fixing collar means this reference already includes the mounting hardware that a bare ZB4BZ009 collar would otherwise supply separately.
