Schneider Electric XB5S2B2L2 Harmony XB5S Biometric Switch Monostable 22 mm 2m Cable 24 V DC Control Unit

The Schneider Electric XB5S2B2L2 is a Harmony XB5S monostable fingerprint biometric switch in a 22 mm dark grey plastic bezel, supplied at 24 V DC with a pre-wired 2 m cable. It replaces a mechanical key switch with momentary fingerprint-based access control for machine commands or area authorization, storing up to 200 users.

Technical Specifications

Certifications & Standards

• CE
• UL
• CSA
• IEC 61000-6-4
• IEC 61000-6-2

Selection Notes

The monostable function outputs only while a valid fingerprint is held at the reader, which suits a momentary enable signal such as a hold-to-run or interlock release; the bistable XB5S2B2L2 sibling, XB5S1B2L2, latches the output instead for an access-enable circuit that should stay on. The pre-wired 2 m cable version suits a panel close enough for direct termination; the M12-connector XB5S2B2M12 variant suits a plug-in field connection instead. With 200 mA switching capacity on a 24 V DC output, it interfaces directly with a PLC digital input.
