Schneider Electric XA2AD25 Harmony XA2 Short Handle Black 2-Position Stay-put 1 NO + 1 NC Selector Switch

The Schneider Electric XA2AD25 is a 2-position Harmony XA2 selector switch with a black short handle, switching 1 NO + 1 NC on a stay-put mechanism. Built for a 22 mm panel cut-out with a plastic body, it carries an IP65 rating and a 3 A AC-15 rating at 240 V for mode-selection and start-circuit control.

Technical Specifications

Certifications & Standards

• CCC
• CE
• UKCA
• GB 14048.1
• IEC 60947-1
• GB 14048.5
• IEC 60947-5-1

Selection Notes

The stay-put mechanism holds the handle in whichever of the 2 positions it is turned to, which suits mode-select functions (such as local/remote or off/hand/auto) that must stay set until an operator deliberately changes them. With 1 NO + 1 NC, this variant gives both a make and a break signal from the same handle position, matching the number of circuits the selector needs to drive. The black short handle and 22.5 mm cut-out keep it interchangeable with the rest of the Harmony XA2 pushbutton line on the same panel face.
