Schneider Electric TM3TI8T Modicon TM3 8 Temperature Inputs PLC I/O Module

% $-358.94
Schneider Electric TM3TI8T Modicon TM3 temperature input module, 8 channels
Schneider Electric TM3TI8T Modicon TM3 temperature input module, 8 channels

Schneider Electric TM3TI8T Modicon TM3 8 Temperature Inputs PLC I/O Module

Brand: Schneider Electric
Reference No: TM3TI8T
Catalog No: TM3TI8T
Series: Modicon TM3
Tariff Code (HS): 853710
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$358.94

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric TM3TI8T is a Modicon TM3 expansion module that adds 8 dedicated temperature inputs for thermocouple (J, K, R, S, B, T, N, E, C) and thermistor (NTC, PTC) sensors, at 16-bit (or 15-bit plus sign) resolution, to Modicon M221, M241, M251 and M262 logic controllers on a 24 V DC supply.

Technical Specifications

Reference TM3TI8T
GTIN 3606480649028
Brand Schneider Electric
Range Modicon TM3
Product Type Analog input module
Range Compatibility Modicon M221, M241, M251, M262
Analogue Input Number 8
Analogue Input Type Thermocouple J/K/R/S/B/T/N/E/C, Thermistor NTC 10k, Thermistor PTC 100-10000 ohm
Analogue Input Resolution 16-bit / 15-bit + sign
Input Impedance 1 megohm minimum
Sampling Duration 100 ms
Conversion Time 100 ms + 100 ms/channel + 1 controller cycle
Repeat Accuracy plus or minus 0.5% FS
Electrical Connection Removable screw terminal, 3.81 mm pitch
Insulation Input-to-supply 1500 V AC, input-to-logic 500 V AC
Current Consumption 30 mA at 24V DC, 45/40 mA at 5V DC
Mounting TH35-15 / TH35-7.5 DIN rail, panel mount
Dimensions (W x D x H) 23.6 x 70 x 90 mm
Net Weight 0.11 kg
IP Degree of Protection IP20
Operating Temperature -10...35 C vertical / -10...55 C horizontal

Certifications & Standards

  • CE
  • UKCA
  • RCM
  • EAC
  • cULus
  • cULus HazLoc
  • IEC 61131-2

Selection Notes

Pick the TM3TI8T when the application needs 8 dedicated temperature channels rather than a mix of signal types. The TM3TI4 in the same range covers only 4 channels but adds current and voltage input options that the TM3TI8T does not support.

Technical Details

Short Description
Modicon TM3 expansion module, 8 temperature inputs, thermocouple and thermistor, 16-bit.
Mounting Type
TH35-15 / TH35-7.5 DIN rail, panel mount
Protection Type
IP20
Catalog No
TM3TI8T
Delivery Date (Days)
30 days
Model Number
TM3TI8T
Tariff Code
853710
