Schneider Electric TM241CEC24R Modicon M241 24-IO CANopen Relay Ethernet PLC

The Schneider Electric TM241CEC24R is a Modicon M241 logic controller with 24 discrete I/O — 14 inputs (8 fast), 6 relay outputs (2 A), and 4 transistor outputs (4 fast) — plus an integrated CANopen master port, powered from 100-240 V AC. It supports up to 63 CANopen server devices alongside Ethernet and dual RS232/RS485 serial connectivity.

Technical Specifications

Certifications & Standards

• CE
• RCM
• cULus
• UKCA
• DNV-GL
• ABS
• LR
• ANSI/ISA 12-12-01
• CSA C22.2 No. 142
• CSA C22.2 No. 213
• IEC 61131-2:2007
• Marine Specification (LR, ABS, DNV, GL)
• UL 508

Selection Notes

The TM241CEC24R adds a dedicated CANopen master port (up to 63 server devices) that the plain TM241CE24T/CE40R do not have, making it the choice when the machine needs to poll CANopen drives or I/O nodes alongside Ethernet and Modbus. Its mixed 6-relay / 4-transistor output block covers both AC/DC switching and 100 kHz PTO positioning on the same 24-point controller.

Applications

Machines integrating CANopen field devices (drives, remote I/O) alongside Ethernet networking and mixed relay/transistor discrete control.
