Schneider Electric PKF32G423 Mureva PK Panel-Mounted 32 A 2P+E 200-250 V IP44 Industrial Socket

% $-11.37
Schneider Electric PKF32G423 Mureva PK Panel-Mounted Industrial Socket – 32 A 2P+E IP44
Schneider Electric PKF32G423 Mureva PK Panel-Mounted Industrial Socket – 32 A 2P+E IP44

Schneider Electric PKF32G423 Mureva PK Panel-Mounted 32 A 2P+E 200-250 V IP44 Industrial Socket

Brand: Schneider Electric
Reference No: PKF32G423
Catalog No: PKF32G423
Tariff Code (HS): 853669
Rated Current: 32 A
Rated Voltage: 200-250 V
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$11.37

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric PKF32G423 is a Mureva PK panel-mounted straight socket rated 32 A, 2P+E, for 200-250 V AC networks. It mounts flush into an equipment panel, uses captive screw terminals, and carries an IP44 degree of protection with a 6 h ground-lug clock position. The grey (RAL 7035) housing uses blue voltage-identification colour coding and a 850 °C fire-resistance rating.

Technical Specifications

Reference PKF32G423
Brand Schneider Electric
Range Mureva PK
Product or component type Socket
Mounting mode Panel-mounted
Shape Straight
Number of poles 2P+E
Rated current (In) 32 A
Rated operational voltage (Ue) 200-250 V
Rated frequency 50/60 Hz
Ground lug clock position 6 h
Connections Captive screws
Cable cross section 2.5-10 mm²
IP degree of protection IP44 (IEC 60529)
IK degree of protection IK08 (EN 62262)
Fire resistance 850 °C (IEC 60695-2-1)
Ambient operating temperature 35 °C
Housing material Self-extinguishing engineering polymer
Contact material Brass
Colour Grey (RAL 7035)
Voltage identification colour Blue
Base dimension 90 x 100 mm
Dimensions (H x W x D) 100 x 90 x 127 mm
Net weight 0.216 kg

Certifications & Standards

  • IEC 60309-1
  • IEC 60309-2

Selection Notes

Pick the PKF32G423 when the socket has to sit flush in an equipment panel or enclosure door with a straight connector body behind the panel face. The IP44 rating covers general indoor industrial use; for outdoor or washdown areas the equivalent IP67 variant in the same 2P+E, 200-250 V configuration is the better fit.

Technical Details

Short Description
Mureva PK panel-mounted straight socket, 32 A, 2P+E, 200-250 V, IP44, captive screw terminals.
Rated Current (Ampere)
32 A
Rated Voltage (VAC)
200-250 V
Mounting Type
Panel-mounted
Protection Type
IP44
Catalog No
PKF32G423
Delivery Date (Days)
30 days
Model Number
Mureva PK Panel-Mounted
Tariff Code
853669
