Schneider Electric METSEPM5660 PowerLogic PM5660 Residual Current Monitoring Class 0.2S 63rd Power Meter

The Schneider Electric METSEPM5660 is a PowerLogic PM5660 flush-mount power meter that adds residual current monitoring with ground current calculation to the PM5560 base platform. It delivers Class 0.2S accuracy to IEC 62053-22 at 128 samples per cycle, measures voltage, current, power, energy and harmonics to the 63rd order, and monitors neutral current directly.

Technical Specifications

Certifications & Standards

• CE
• cULus
• EN 50470-1
• EN 50470-3
• IEC 61557-12
• IEC 62053-22
• ANSI C12.20

Selection Notes

The PM5660 adds residual current (I0) monitoring to the PM5560 base, calculating a ground-fault indication from the measured phase and neutral currents without a separate core-balance CT. That makes it suited to feeders where early insulation-degradation or earth-leakage trending matters more than waveform disturbance analysis. Where sag/swell waveform capture is the priority instead, the PM5650 covers that function on the same base platform; the PM5760 combines both.
