Schneider Electric METSEPM5563RD PowerLogic PM5563 Power Meter DIN Mounted Remote Power Meter Accessory

% $-651.19
Schneider Electric METSEPM5563RD PowerLogic PM5563 power meter with remote display - Class 0.2S 63rd harmonic
Schneider Electric METSEPM5563RD PowerLogic PM5563 power meter with remote display - Class 0.2S 63rd harmonic

Schneider Electric METSEPM5563RD PowerLogic PM5563 Power Meter DIN Mounted Remote Power Meter Accessory

Brand: Schneider Electric
Reference No: METSEPM5563RD
Catalog No: METSEPM5563RD
Tariff Code (HS): 853890
Rated Current: 1 A / 5 A
Rated Voltage: 20-400 V AC L-N / 20-828 V AC L-L
Communication: RS485 Modbus RTU/ASCII, 2x Ethernet Modbus TCP/IP, BACnet IP, DNP3
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$651.19

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric METSEPM5563RD is a PowerLogic PM5563 DIN-rail power meter fitted with a 96 x 96 mm remote LCD display. It delivers Class 0.2S accuracy to IEC 62053-22 at 128 samples per cycle, measures voltage, current, power, energy and harmonics to the 63rd order, and monitors neutral current directly with calculated ground current over dual Ethernet and RS485 Modbus.

Technical Specifications

Reference METSEPM5563RD
GTIN 3606480761416
Brand Schneider Electric
Range PowerLogic PM5000
Device Short Name PM5563
Accuracy Class Class 0.2S active energy (IEC 62053-22)
Power Quality Analysis Up to the 63rd harmonic
Sampling Rate 128 samples/cycle
Rated Supply Voltage (Us) 90-528 V AC 45-65 Hz / 100-300 V DC
Rated Current Input (In) 1 A or 5 A
Network Type 1P+N, 3P, 3P+N
Measurement Voltage 20-400 V AC phase-neutral / 20-828 V AC phase-phase
Metering Type Measured neutral current, calculated ground current
Digital Inputs 4, WAGES-capable
Digital Outputs 2
Alarms 52 configurable
Display Remote LCD, 128 x 128 px
Communication RS485 Modbus RTU/ASCII; 2 x Ethernet RJ45, Modbus TCP/IP, BACnet/IP, DNP3
Memory Capacity 1.1 MB
Mounting Clip-on, DIN rail
IP Rating IP30 rear / IP54 display
Dimensions (W x D x H) 96 x 72 x 96 mm
Weight 0.45 kg

Certifications & Standards

  • CE
  • cULus
  • BTL
  • EN 50470-1
  • IEC 61557-12
  • IEC 62053-22
  • ANSI C12.20

Selection Notes

The PM5563RD pairs the DIN-rail PM5563 meter body with a separate 96 x 96 mm remote LCD, so the metering electronics can sit behind a panel while the display is flush-mounted at eye level on the door - a layout the plain PM5563 (no display) and the flush-mount PM5560 cannot offer together. Choose this variant when the installation needs both DIN-rail metering density and a local readout; choose the PM5563 instead when the meter reports only to Ethernet/RS485 and no local display is needed.

Technical Details

Short Description
PowerLogic PM5563 DIN-rail power meter with remote LCD display, Class 0.2S accuracy, 63rd harmonic, dual Ethernet.
Rated Current (Ampere)
1 A / 5 A
Rated Voltage (VAC)
20-400 V AC L-N / 20-828 V AC L-L
Mounting Type
Clip-on, DIN rail
Protection Type
IP30 rear / IP54 display
Catalog No
METSEPM5563RD
Delivery Date (Days)
30 days
Model Number
PM5563
Tariff Code
853890
