Schneider Electric LTMTEBD TeSys Tera Ethernet TCP/IP 24 V DC Motor Controller Motor Starter Module

% $-921.44
Schneider Electric LTMTEBD TeSys Tera Ethernet TCP/IP motor controller - 24 V DC
Schneider Electric LTMTEBD TeSys Tera Ethernet TCP/IP motor controller - 24 V DC

Schneider Electric LTMTEBD TeSys Tera Ethernet TCP/IP 24 V DC Motor Controller Motor Starter Module

Brand: Schneider Electric
Reference No: LTMTEBD
Catalog No: LTMTEBD
Tariff Code (HS): 853650
Communication: Ethernet TCP/IP
Stock: 0
Delivery time: 30 business day(s)
Shipping Origin: Türkiye EXW
$921.44

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Schneider Electric LTMTEBD is a TeSys Tera main motor management controller communicating over Ethernet TCP/IP, powered at 24 V DC, providing full protection, control and monitoring of single-phase and three-phase AC induction motors when paired with a TeSys Tera sensor module and a contactor.

Technical Specifications

Reference LTMTEBD
GTIN 3606482184763
Brand Schneider Electric
Range TeSys Tera
Device short name LTMT
Product or component type Motor controller
Device application Equipment monitoring and control
[Us] rated supply voltage 24 V DC
Supply voltage limits 18...30 V DC
Current consumption 56...127 mA
Communication port protocol Ethernet TCP/IP
Bus type Ethernet IEEE 802.3, 10...100 Mbit/s, 2x RJ45
[Ui] rated insulation voltage 690 V AC
[Uimp] rated impulse withstand voltage 0.8 kV
Short-circuit withstand 100 kA
Overvoltage category III
Logic input number 4
Contacts type and composition 2 NO fault signal | 1 NO + 1 NC fault signal
Current measurement range (via sensor modules) 0.3-100 A internal sensor modules, up to 810 A with external current transformers
Maximum operating rate 1800 cyc/h
Dimensions (H x W x D) 45 x 112 x 90 mm
IP degree of protection IP20
Ambient air temperature for operation -20...70 °C

Certifications & Standards

  • UL
  • IEC
  • cUL
  • EN/IEC 60947-4-1
  • UL/CSA 60947-4-1

Selection Notes

The EBD is the Ethernet TCP/IP variant on a 24 V DC supply; choose the EFM sibling instead if the panel's control supply is 100-240 V AC/DC, or the MBD/PBD/PFM variants for Modbus RTU or Profibus DP networks.

Technical Details

Short Description
TeSys Tera main controller, Ethernet TCP/IP, 24 V DC supply, motor protection and monitoring
Mounting Type
DIN rail
Protection Type
IP20
Catalog No
LTMTEBD
Delivery Date (Days)
30 days
Model Number
TeSys Tera (LTMT)
Tariff Code
853650
