Schneider Electric LE1M35N714 TeSys LE enclosed DOL starter - 5.5-8 A 415 V AC

Schneider Electric LE1M35N714 TeSys LE DOL Starter 3P 5.5-8 A 3 kW 415 V AC Coil IP65 Motor Starter

Name: Schneider Electric LE1M35N714 TeSys LE DOL Starter 3P 5.5-8 A 3 kW 415 V AC Coil IP65 Motor Starter
Brand: Schneider Electric
SKU: LE1M35N714
Price: 66.07 USD
Availability: OutOfStock
Rating: 5.0 (10 reviews)

Brand: Schneider Electric

Reference No: LE1M35N714

Tariff Code (HS): 853620

Rated Current: 5.5-8 A

Power: 3 kW

Rated Voltage: 415 V AC

Stock: 0

Delivery time: 30 business day(s)

Shipping Origin: Türkiye EXW

$66.07

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

Description

The Schneider Electric LE1M35N714 is a TeSys LE enclosed direct-on-line starter with a built-in LC1K contactor and LR2K thermal overload relay, pre-wired for 3 kW motors at 400 V with a thermal setting range of 5.5-8 A and a 415 V AC control circuit. A yellow operating LED gives local run status, and the compact 78 x 160 x 108 mm enclosure suits small fractional-kW motors.

Technical Specifications

Reference	LE1M35N714
GTIN	3389110781205
Brand	Schneider Electric
Range	TeSys LE
Device short name	LE1M
Product type	Enclosed DOL starter
Device composition	Contactor LC1K + thermal overload relay LR2K (built-in, pre-wired)
Utilisation category	AC-3
Thermal protection adjustment range	5.5-8 A
[Uc] control circuit voltage	415 V AC 50/60 Hz
Motor power (380/400 V AC)	3 kW
Control type	Push-button start (green I) / stop-reset (red O)
Local signalling	Operating LED (yellow)
Enclosure material	ABS (acrylonitrile butadiene-styrene)
IP degree of protection	IP65
Dimensions (W x H x D)	78 x 160 x 108 mm
Net weight	0.6 kg
Ambient air temperature for operation	-5...40 °C
Country of origin (manufacturing)	CZ

Certifications & Standards

UKCA
IEC 60947-4-1

Selection Notes

This 5.5-8 A thermal setting covers 3 kW motors at 400 V in the LE1M35 line; move to a lower or higher adjustment-range variant as motor power changes, keeping the same 415 V AC control voltage if the panel's control circuit is already wired for it. Because the overload relay is built in and pre-wired, there is no separate LR2K to size or order, unlike the LE1D range that ships with the contactor only.

Technical Details

Short Description

TeSys LE enclosed DOL starter, 3P, 5.5-8 A AC-3, 3 kW at 400 V, 415 V AC coil, IP65

Rated Current (Ampere)

5.5-8 A

Rated Voltage (VAC)

415 V AC

Mounting Type

Surface mounting, screw fixing

Protection Type

IP65

Power (kW)

3 kW

Delivery Date (Days)

30 days

Model Number

TeSys LE (LE1M)

Tariff Code

853620
