Schneider Electric LC1G150EHEN TeSys Giga Contactor 3P 3NO AC-3 150 A 48-130 V AC/DC Coil Contactor

The Schneider Electric LC1G150EHEN is a 3-pole TeSys Giga high-power contactor rated 150 A AC-3 (75 kW at 400 V) for direct motor starting, with a separate AC-1 rating of 275 A for pure power switching. It runs on a 48-130 V AC/DC wide-band electronic coil with built-in peak limiting and ships with a 1 NO + 1 NC auxiliary contact block, mounted on a plate 108 mm wide.

Technical Specifications

Certifications & Standards

• CB Scheme
• CCC
• cULus
• EAC
• CE
• UKCA
• EU-RO-MR by DNV-GL
• EN/IEC 60947-4-1
• EN/IEC 60947-5-1
• UL 60947-4-1
• CSA C22.2 No 60947-4-1
• JIS C8201-4-1
• JIS C8201-5-1
• IEC 60335-1
• IEC 60335-2-40
• UL 60335-1
• UL 60335-2-40

Selection Notes

The AC-3 rating of 150 A (75 kW at 400 V) sizes this contactor for direct-on-line motor starting; its AC-1 rating of 275 A applies only to resistive switching, not motor duty. Local Contact Wear Diagnosis flags power-contact wear before failure, and the switching module can be replaced in place without removing busbars. Pick a higher-current Giga variant in the same range if the motor's AC-3 current exceeds this frame's rating.
