Schneider Electric C160N420FM ComPacT NS1600N 4P 1600 A 50 kA MicroLogic 2.0 Moulded Case Circuit Breaker

The Schneider Electric C160N420FM is a 4-pole, 1600 A ComPacT NS1600N moulded case circuit breaker rated for a breaking capacity of 50 kA at 380/415 V AC. It carries a MicroLogic 2.0 electronic trip unit with long-time and instantaneous (LI) protection and an operational voltage of 690 V AC, suited for fixed, manually-operated distribution boards up to 1600 A.

Technical Specifications

Certifications & Standards

• IECEE CB Scheme
• EN/IEC 60947-2

Selection Notes

The MicroLogic 2.0 trip unit on the C160N420FM provides long-time overload (L) and instantaneous short-circuit (I) protection only — there is no short-time delay stage, so this 4-pole, 1600 A breaker suits a terminal or feeder position rather than a selective main incomer. Step up to the 5.0 (LSI) trip unit in the same NS1600N frame when the installation needs short-time discrimination with downstream devices, or to 6.0 (LSIG) when ground-fault tripping must also be integrated.
