Siemens 6ES7522-5FF00-0AB0 SIMATIC S7-1500 DQ 8x230VAC/2A ST 8-Channel Triac PLC I/O Module

The Siemens 6ES7522-5FF00-0AB0 is a SIMATIC S7-1500 digital output module, type DQ 8x230VAC/2A ST, with 8 Triac outputs rated 120/230 V AC and 2 A per channel. Each channel carries a built-in 6.3 A slow-blow fuse, and total module current is limited to 10 A. Front connectors are ordered separately.

Technical Specifications

Selection Notes

Each of the 8 channels is isolated individually (groups of 1), so a fault on one output does not affect the others, unlike modules that isolate in larger groups. The 6.3 A slow-blow fuse per channel is sized above the 2 A rated output to absorb inrush from lamp or small-motor loads without nuisance tripping, and two outputs can be paralleled for redundant control of a single load. The 10 Hz maximum switching frequency on resistive loads and 0.5 Hz on inductive loads mark this as a standard switching module, not suited to high-frequency PWM-style control; use a DC or solid-state output module for that. Front connectors (screw-terminal or push-in) are not included.

Applications

Switching 230 V AC loads such as contactor coils, indicator lamps, and solenoid valves directly from an S7-1500 station, including redundant shutdown paths using the paralleled-output function.
