Siemens 6ES7135-7TD00-0AB0 ET200iSP 4AO HART 4-20mA Ex Zone 1 Remote I/O Module

% $-758.94
Siemens 6ES7135-7TD00-0AB0 ET200iSP 4AO HART Remote I/O Module
Siemens 6ES7135-7TD00-0AB0 ET200iSP 4AO HART Remote I/O Module

Siemens 6ES7135-7TD00-0AB0 ET200iSP 4AO HART 4-20mA Ex Zone 1 Remote I/O Module

Brand: Siemens
Reference No: 6ES7135-7TD00-0AB0
Catalog No: 6ES7135-7TD00-0AB0
Series: SIMATIC ET 200SP
Tariff Code (HS): 85389091
Rated Current: 4-20 mA (output range)
Communication: HART protocol V6.0
Stock: 0
Delivery time: 10-15 business day(s)
Shipping Origin: Türkiye EXW
$758.94

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Siemens 6ES7135-7TD00-0AB0 is an ET200iSP electronic module with 4 analog current outputs for HART field devices, certified Ex ib [ia Ga] IIC T4 Gb for ATEX and IECEx Zone 1 hazardous areas. It drives a 4-20 mA or 0-20 mA signal over a two-wire connection up to 750 ohm load, with HART protocol version 6.0 and 14-bit resolution.

Technical Specifications

SKU 6ES7135-7TD00-0AB0
Brand Siemens
Series SIMATIC ET200iSP
Product Type Designation 4AQ I HART
HW Functional Status 17
Firmware Version V3.0.4
Number of Analog Outputs 4
Output Ranges 0 to 20 mA, 4 to 20 mA, two-wire connection
Load Impedance, max. 750 ohm (current outputs)
Resolution, max. 14 bit (with overrange)
Settling Time (resistive load) 4 ms
Supply Voltage (DC) 20.4-28.8 V
Current Consumption, typ. 295 mA
Power Loss, typ. 2.7 W
Cable Length, shielded, max. 500 m
Wire-break Diagnosis Yes, I load greater than 1 mA
Short-circuit Diagnosis Yes, I load greater than 1 mA
IP Degree of Protection IP30
ATEX Marking II 2 G (1) G Ex ib [ia Ga] IIC T4 Gb, II 2 G (1) D Ex ib [ia IIIC Da] IIC T4 Gb, I M2 Ex ib [ia] I Mb
IECEx Certificate IECEx KEM 05.0012
Connection Method Screw/spring-type terminal
Width x Height x Depth 30 x 129 x 136.5 mm
Net Weight 0.337 kg
Country of Origin DE

Selection Notes

The 750 ohm max. load impedance and two-wire current output cover most HART positioners and I/P converters wired directly from the classified zone, without a separate isolation barrier for the output signal. Pick this 4AO HART module over the 4AI HART input card when the ET200iSP station needs to drive field actuators rather than read transmitters; the two share the same Ex ib Zone 1 rating and IECEx approval family.

Technical Details

Short Description
ET200iSP 4AO HART module, 4-20mA current output, Ex ib Zone 1, 14-bit, 750 ohm load.
Rated Current (Ampere)
4-20 mA (output range)
Mounting Type
Front/rail mounting, ET200iSP
Protection Type
IP30, Ex ib Zone 1/Zone 21
Catalog No
6ES7135-7TD00-0AB0
Delivery Date (Days)
10-15 days
Model Number
6ES7135-7TD00-0AB0
Tariff Code
85389091
