Siemens 6ES7134-7SD00-0AB0 ET200iSP 4AI TC Thermocouple Ex Zone 1 Remote I/O Module

% $-843.84
Siemens 6ES7134-7SD00-0AB0 ET200iSP 4AI TC Thermocouple Remote I/O Module
Siemens 6ES7134-7SD00-0AB0 ET200iSP 4AI TC Thermocouple Remote I/O Module

Siemens 6ES7134-7SD00-0AB0 ET200iSP 4AI TC Thermocouple Ex Zone 1 Remote I/O Module

Brand: Siemens
Reference No: 6ES7134-7SD00-0AB0
Catalog No: 6ES7134-7SD00-0AB0
Series: SIMATIC ET 200SP
Tariff Code (HS): 85389091
Stock: 0
Delivery time: 10-15 business day(s)
Shipping Origin: Türkiye EXW
$843.84

Your purchase is backed by Warranty – learn more.

Hassle-free Returns – learn more.

  • Description

The Siemens 6ES7134-7SD00-0AB0 is an ET200iSP electronic module with 4 analog thermocouple inputs, certified Ex ib [ia Ga] IIC T4 Gb for installation in ATEX and IECEx Zone 1 hazardous areas. It accepts thermocouple types B, C, E, J, K, L, N, R, S, T and U plus a -80 mV to +80 mV voltage range, with 16-bit resolution and internal cold-junction compensation.

Technical Specifications

SKU 6ES7134-7SD00-0AB0
Brand Siemens
Series SIMATIC ET200iSP
Product Type Designation 4AI TC
HW Functional Status 7
Firmware Version V1.0.1
Number of Analog Inputs 4
Input Ranges Voltage -80 to +80 mV; Thermocouple types B, C, E, J, K, L, N, R, S, T, U
Resolution, max. 16 bit (with overrange)
Basic Conversion Time 80 ms at 50 Hz / 66 ms at 60 Hz
Temperature Compensation Internal (via supplied TC sensor module) or external
Supply Voltage (DC) 20.4-28.8 V
Current Consumption, typ. 17 mA
Power Loss, typ. 0.4 W
Cable Length, shielded, max. 50 m
Wire-break Diagnosis Yes, R greater than 1.7 kOhm
IP Degree of Protection IP30
ATEX Marking II 2 G (1) G Ex ib [ia Ga] IIC T4 Gb, II 2 G (1) D Ex ib [ia IIIC Da] IIC T4 Gb, I M2 Ex ib [ia] I Mb
IECEx Certificate IECEx KEM 05.0008
Connection Method Screw/spring-type terminal
Width x Height x Depth 30 x 129 x 136.5 mm
Net Weight 0.32 kg
Country of Origin DE

Certifications & Standards

  • GL
  • ABS
  • BV
  • DNV

Selection Notes

The internal cold-junction compensation via the supplied TC sensor module means this 4AI TC card needs no external compensation socket, unlike modules that rely on a separate analog channel for reference temperature. Its Ex ib [ia Ga] IIC T4 Gb rating restricts it to Zone 1 gas and Zone 21 dust areas rather than Zone 0; pick the HART 2-wire variant instead when the field instrument is a 4-20 mA transmitter rather than a bare thermocouple.

Technical Details

Short Description
ET200iSP 4AI TC module, 4 thermocouple inputs, Ex ib Zone 1, 16-bit, internal cold-junction comp.
Mounting Type
Front/rail mounting, ET200iSP
Protection Type
IP30, Ex ib Zone 1/Zone 21
Catalog No
6ES7134-7SD00-0AB0
Standards
Germanischer Lloyd (GL), American Bureau of Shipping (ABS), Bureau Veritas (BV), Det Norske Veritas (DNV)
Delivery Date (Days)
10-15 days
Model Number
6ES7134-7SD00-0AB0
Tariff Code
85389091
