ABB 1SDA070822R1 E1.2B 1250 Ekip Dip LSI 3p F F 1250A 3P 42kA Fixed Power Circuit Breaker

The ABB 1SDA070822R1 E1.2B 1250 Ekip Dip LSI 3p F F is a 1250 A, 3-pole fixed-mount power circuit breaker from the SACE Emax2 E1.2 series, delivering a breaking capacity of 42 kA at 400 V AC. Equipped with the Ekip Dip LSI protective release unit, this air circuit breaker provides advanced Long-time, Short-time, and Instantaneous protection functions, making it a robust solution for transformer, generator, and installation protection in demanding industrial environments.

Technical Specifications

Certifications & Standards

• CE: Conforms to European Economic Area product safety and performance directives
• IEC: Designed and tested in accordance with IEC standards
• IEC 60947: Compliant with IEC 60947 low-voltage switchgear and controlgear standard
• UL 2799: Listed to UL 2799 standard for electrical systems
• ATEX: Certified for use in potentially explosive atmospheres
• CSA: Certified to Canadian Standards Association requirements
• VDE: Tested and approved to VDE German electrotechnical standards
• RoHS: Compliant with EU Directive 2011/65/EU Restriction of Hazardous Substances
• REACH: Compliant with EU REACH regulation on chemical substances
• EU Directive 2011/65/EU: RoHS Directive compliance confirmed
• Amendment 2015/863: Compliant with the updated RoHS substance restrictions under EU 2015/863
• WEEE: Registered under the Waste Electrical and Electronic Equipment directive for responsible disposal

Applications & Use Cases

• Transformer protection in industrial power distribution panels
• Generator protection in standby and prime power installations
• Main incomer protection for industrial switchboards and MCC panels
• Bus-coupler and feeder protection in low-voltage distribution systems
• Protection of large motor loads and critical process installations
• Data centre and utilities infrastructure power protection

Frequently Asked Questions

What protection functions does the Ekip Dip LSI release provide?

The Ekip Dip LSI release provides three levels of protection: Long-time (L) for overload protection, Short-time (S) for delayed short-circuit protection, and Instantaneous (I) for immediate response to high fault currents. Settings are configured via DIP switches directly on the release unit.

What is the breaking capacity of the E1.2B 1250 Ekip Dip LSI 3p F F at 400 V AC?

The rated ultimate breaking capacity (Icu) is 42 kA at 400 V AC, as specified in the SACE Emax2 product family documentation.

Is this breaker withdrawable or fixed?

This is a fixed-mount (F F) unit. It is designed for permanent installation within a switchboard or distribution panel. A withdrawable variant is available separately in the Emax2 product range.

What are the physical dimensions and weight?

The E1.2B 1250 Ekip Dip LSI 3p F F measures 210 mm (width) × 296 mm (height) × 183 mm (depth) and weighs 14 kg.
