Siemens 6XV1873-5AH10 SIMATIC NET FO Standard Cable GP 50/125 1m LC Duplex Industrial Network Cable

The Siemens 6XV1873-5AH10 is a SIMATIC NET FO Standard Cable GP, a 50/125 µm multimode fiber-optic cable pre-assembled with 2x LC duplex connectors at 1.0 m length. It carries Industrial Ethernet and PROFIBUS optical links with 2.7 dB/km attenuation at 850 nm and c(UL)us OFN FT4 approval. Maximum reach is 3,000 m over PROFIBUS and up to 2,000 m for 1000BaseLX Industrial Ethernet runs.

Technical Specifications

Certifications & Standards

• RoHS

Selection Notes

This 1.0 m length is the shortest pre-assembled option in the FO Standard Cable GP LC-duplex range, suited for short jumper runs inside a cabinet or between adjacent panels rather than plant-floor backbone distances. For longer PROFIBUS or Industrial Ethernet segments, use the longer pre-assembled lengths in the same OM2 50/125 cable type, up to the 3000 m and 2000 m limits listed above.

Applications

Used as a short-run LC-duplex patch cable between SIMATIC NET Industrial Ethernet switches or PROFIBUS-to-fiber converters inside a control cabinet, or to bridge two adjacent enclosures on a machine.
