Siemens 6XV1873-3AT10 SIMATIC NET FO Standard Cable 50/125 100m 4xBFOC Network Cable

The Siemens SIMATIC NET FO Standard Cable (6XV1873-3AT10) is a 100 m preassembled glass fiber-optic cable with four BFOC connectors, built on 50/125 µm OM2 multimode gradient fiber for Industrial Ethernet and PROFIBUS links. It carries UL approval for indoor/outdoor runs and supports 100BaseFX segments up to 5000 m or 1000BaseSX segments up to 750 m.

Technical Specifications

Certifications & Standards

• RoHS

Selection Notes

At 100 m this preassembled length covers longer cabinet-to-cabinet or inter-floor runs in one continuous pull, avoiding a field-terminated splice that the shorter 50 m variant would need on the same distance. The four-BFOC termination pre-configures the cable as two independent fiber pairs, so a single reel can serve one Industrial Ethernet or PROFIBUS link, or two shorter segments from a common patch panel. The 45 mm single-bend radius and 1200 N short-term tensile rating are the limits to check against cable tray routing before ordering, since exceeding either during pulling degrades the attenuation figures.

Applications

Fiber backbone links between Industrial Ethernet switches or PROFIBUS segments across separate control cabinets, floors, or buildings where copper runs would exceed distance or EMI limits. UL-listed jacket allows the same cable type indoors and in protected outdoor runs.
