Siemens 6RA8075-6DS22-0AA0 SINAMICS DCM 400V 174A to 485V DC 210A Two-Quadrant DC Converter

The Siemens 6RA8075-6DS22-0AA0 is a SINAMICS DCM two-quadrant DC converter with a B6C bridge connection, rated for a 400 V 3AC, 174 A controllable input and a 485 V DC, 210 A output through the D485/210 MRE-GEEF6S22 field rectifier. It weighs 15.0 kg and is manufactured in China.

Technical Specifications

Selection Notes

At 210 A output through the D485/210 field rectifier, this unit covers roughly double the current of the 90 A version in the same B6C two-quadrant family, so it fits larger DC motor loads without changing the control architecture. The two-quadrant topology gives controlled motoring and regenerative braking into the DC bus but not full four-quadrant reversing; projects needing lower current only should look at the smaller-frame SINAMICS DCM converter in the same range instead of derating this unit.

Applications

Thyristor-based control of larger separately excited DC motors in two-quadrant duty such as extruders, winders, and hoists where controlled deceleration is required at higher current than the smallest SINAMICS DCM frame supports.
