Siemens 6GK1901-0DA20-0AA0 SIMATIC NET BFOC Connector Set 20-Piece Multimode Fiber Optic Connector
Brand:
Siemens
Reference No:
6GK1901-0DA20-0AA0
Catalog No:
6GK1901-0DA20-0AA0
Series:
SIMATIC NET
Tariff Code (HS):
85367000
Get Quote
Communication:
Industrial Ethernet 10/100 Mbit/s, PROFIBUS 9.6 kbit/s-12 Mbit/s
Stock:
0
Delivery time:
10-15 business day(s)
Shipping Origin:
Türkiye EXW
$308.47
- Description
The Siemens 6GK1901-0DA20-0AA0 is a SIMATIC NET BFOC connector set of 20 ST/BFOC plugs for terminating multimode 50/125 and 62.5/125 glass fiber-optic cable. The bayonet-locking metal-and-plastic housing is rated IP20 and supports 10/100 Mbit/s Industrial Ethernet or 9.6 kbit/s to 12 Mbit/s PROFIBUS transmission. Field assembly requires special tools and gluing-and-polishing technique.
Technical Specifications
| Catalog No | 6GK1901-0DA20-0AA0 |
| SKU | 6GK1901-0DA20-0AA0 |
| Brand | Siemens |
| Series | SIMATIC NET |
| Product Type Designation | BFOC Connector Set |
| Product Description | 20 ST/BFOC plug |
| Suitability | For connection of glass fiber-optic cables (50/125 - 62.5/125) |
| Transfer Rate (Industrial Ethernet) | 10, 100 Mbit/s |
| Transfer Rate (PROFIBUS) | 9.6 kbit/s ... 12 Mbit/s |
| Optical Interfaces | 1 |
| Interface Design | BFOC connector |
| Enclosure Material | Metal and plastic |
| Locking Mechanism | Bayonet |
| Cable Outlet | 180° |
| Width | 9.5 mm |
| Height | 9.5 mm |
| Depth | 29.7 mm |
| Net Weight | 8 g |
| Operating Temperature | -40 ... +85 °C |
| Storage Temperature | -40 ... +90 °C |
| Transport Temperature | -40 ... +90 °C |
| Protection Class IP | IP20 |
| Silicon-Free | Yes |
| Strain Relief | Yes |
| Country of Origin | DE |
| EAN | 4019169402415 |
Certifications & Standards
- RoHS
Technical Details
Short Description
SIMATIC NET BFOC connector set, 20 ST/BFOC plugs for multimode fiber-optic cable, IP20, bayonet lock, field assembly.
Protection Type
IP20
Catalog No
6GK1901-0DA20-0AA0
Standards
RoHS conformity
Delivery Date (Days)
10-15 days
Model Number
6GK1901-0DA20-0AA0
Tariff Code
85367000
