Siemens 6ES7233-4HD50-0XB0 SIMATIC S7-1200 SB 1233 Analog I/O 2AI/2AQ PLC I/O Module

The Siemens 6ES7233-4HD50-0XB0 is a SIMATIC S7-1200 SB 1233 signal board that adds 2 analog inputs and 2 analog outputs directly to the CPU front, each with 14-bit resolution. Inputs accept +/-10V, +/-5V, +/-2.5V or 0-20mA/4-20mA; outputs cover +/-10V, 0-20mA or 4-20mA. Cycle time across all channels is 0.625ms, and the board draws its supply from the CPU's 24V DC bus.

Technical Specifications

Certifications & Standards

• CE mark
• UL approval
• cULus
• RCM
• KC approval

Selection Notes

The SB 1233 mounts on the S7-1200 CPU front and does not occupy a rack slot, so it is the option to reach for when a station needs a small increment of analog I/O rather than a full SM module. Because it carries both 2 AI and 2 AQ on the same board, it covers one measurement loop and one control loop from a single expansion, and the shared 14-bit resolution on both sides keeps input scaling and output trim consistent without mixing module classes. The 0.625ms cycle time across all channels is fast enough for closed-loop trim on machine-level analog signals rather than slow process monitoring only.

Applications

Typical use is adding a single 4-20mA sensor input and a 0-10V setpoint output to a compact S7-1200 station without expanding the rack footprint, for example on skid-mounted equipment, small process modules, or machine builder panels that need analog trim alongside the CPU's onboard digital I/O.
