Siemens 6ES7142-6BR00-0BB0 SIMATIC ET 200eco PN DQ 8x24VDC/2A M12-L Remote I/O Module

The Siemens 6ES7142-6BR00-0BB0 is a SIMATIC ET 200eco PN digital output module with 8 channels rated 2 A at 24 V DC, wired through 2x M12-L PROFINET ports plus M12 I/O connectors in an IP65/67/69K housing rated for washdown environments. It runs isochronous mode down to a 250 microsecond cycle and supports PROFINET S2 system redundancy with MRP media redundancy.

Technical Specifications

Selection Notes

Choose the 2 A version over the 0.5 A module in the same family when driving solenoid valves or small motor loads rather than pilot lamps - the higher 4 A response threshold and 8 A total module current give it headroom the 0.5 A variant does not have. Both share the same PROFINET S2 redundancy, MRP media redundancy, and per-channel wire-break/short-circuit diagnostics with configurable substitute values. IP65/67/69K sealing keeps it field-mountable on washdown lines without a rated enclosure.

Applications

Field-mounted actuator control on PROFINET networks - solenoid valves, contactor coils, and small motor loads up to 2 A per channel in washdown or network-redundant machine and packaging lines.
